No.29 M Trek FX+2 LT lightweight
No.28 M Trek FX+2 LT lightweight 2025
Range extender compatible
Used Price: £1685
New RRP: £2125
Postage
Included - Tracked 48 UK mainland
Size: Medium
165 - 175 cm
5'5" - 5'9"
Colour
Viper Red
Trek FX+2 LT lightweight Spec
Specification
Frameset
Frame Alpha Gold Aluminium, internal cable routing, internal battery, rack and mudguard mounts, kickstand mount
Fork Alloy, internal brake routing, fender mounts, rack mounts, ThruSkew 5mm QR
Wheels
Hub front Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Skewer front 132x5 mm QR
Hub rear Hyena hub drive motor, 40 Nm, 250 W
Rim Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Spokes 14 g stainless steel, black
Tyre Bontrager H2 Comp, reflective strip, wire bead, 30 tpi, 700x40 mm
Max tyre size 50mm without mudguards, 45mm with mudguards
E-system
Battery 250 Wh, integrated in down tube
Charger 2A, 42V output, 100V–240V AC input
Computer LED display
Drivetrain
Shifter Shimano M315, 8-speed
Rear derailleur Shimano Acera M3020-8, 40T max cog
*Crank Size: S, M
ProWheel Pro alloy, 42T narrow-wide steel ring, 170 mm length
Size: L, XL
ProWheel Pro alloy, 42T narrow-wide steel ring, 175 mm length
Bottom bracket Torque sensor, threaded, 122.5 mm spindle
Cassette Shimano HG400, 11-40, 8-speed
Chain KMC Z8.3
Pedal slip-proof pedals with reflectors
Max. chainring size 1x: 44T
Components
Saddle Bontrager Sport
*Seatpost Size: S, M
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: L, XL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
*Handlebar Size: S, M
Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width
Size: L, XL
Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width
Grips Bontrager XR Endurance Comp, lock-on
*Stem Size: S, M
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length
Size: L, XL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length
Brake Shimano hydraulic disc, MT200 lever, UR300 calliper
Brake rotor Shimano RT26, 6-bolt, 160 mm
Rotor size Max brake rotor sizes: 160 mm front and rear
Accessories
*Light Size: S, M, L, XL
Herrmans MR4, 120-lumen LED
Size: S, M, L, XL
Spanninga Solo
Kickstand Pletscher Comp 18
Cargo rack MIK-compatible alloy rear rack, maximum load 25 kg
*Mudguard Size: S, M, L, XL
SKS plastic, rear
Size: S, M, L, XL
SKS plastic, front
Weight
Weight M - 17.75 kg / 39.14 lb
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
